What are the package sizes of FPC cable pogopin connectors and how to package them.sewing thimble pr

　　FPC cable pogopin connector, now most people know very little about it. For example, FPC cable pogopin connector packaging size and FPC pogopin connector specifications and other knowledge points, FPC cable pogopin connector is now divided into 0.3mm, 0.5mm, 1.0mm, etc., pogopin connector packaging size is also different.

　　FPC cable pogopin connector packaging method:

　　For the pogopin connector with a small package size for the FPC cable pogopin connector, the package is required to protect the coplanarity of the pogopin connector terminal and the front side of the terminal arrangement. There are usually two packaging methods: PVC tube packaging and carrier tape packaging.

　　When the packaging size of the FPC cable pogopin connector is small, it is recommended to use tape packaging. The PVC tube packaging has poor protection performance for the small spacing PVC pogopin connector. The product needs to be manually placed on the PCB during the SMT process, which increases the line in the assembly. External technology seriously affects production efficiency.

　　For example, the choice of tape packaging is the packaging method of mounting electronic components along the surface of ICs. First, the size of the packaging tape designed according to the product shape on the front page can protect the product from damage. It can be automated in the same way as other electronic components in the SMT process. SMD soldering process does not require extra processes and equipment
