Introduction to the use of pogopin connectors

　　Pogo Pin is a spring-type probe formed by riveting the three basic components of needle (Plunger), needle tube (Tube) and spring (Spring) by precision instruments, also known as pogo pin, pogo pin, spring Probes, SpringLoaded, PogoPin connectors.

　　The bottom of the needle (Plunger) of the PogoPin is usually a bevel structure. The function of the bevel structure is to ensure that the PogoPin keeps the needle (Plunger) in contact with the inner wall of the needle (Tube) when it is working, so that the current mainly passes through the gold-plated needle (Plunger) and the needle (Tube). ) to ensure PogoPin stability and low impedance. PogoPin is generally used for precision connections in electronic products such as mobile phones, communications, automobiles, medical care, aerospace and other electronic products;

　　Since PogoPin is a very fine probe, the volume can be made very small, so it can reduce the weight of the connector, save space, and beautify the appearance of products (such as ultra-thin mobile
