Magnetic adsorption connection method in magnetic connector

　　The core advantage of the magnetic connector over the traditional plug-in connector is that the connectors at both ends of the male and female can make the pogopin contact to realize the charging function through magnetic automatic adsorption. Suction method and magnet and alloy pair suction method

　　1. The specific structure of the magnet and the magnet at the male and female ends of the magnetic suction connector includes the following three types:

　　1. Direct suction method

　　2. The unilateral magnet separates the suction method

　　3. The magnets on both sides are separated by the suction method

　　2. The magnets and alloys of the male and female ends of the magnetic suction joint include the following two methods:

　　1. Direct suction method

　　2. Unilaterally separated suction method
